Raritan DKX2-232

                 List Price: $4,595.00

                  Request A Quote

                  Data Sheet

  • 32 Server Ports, 2-Remote Users
  • 1-Local Port
  • Dual Power, Dual Ethernet
  • Virtual Media, LDAP Integration
  • 1U (includes rack brackets)

    The next-generation DKX2-232 features multi-user access at an attractive price per port for a 2-channel KVM switch. It provides two remote users and one local user BIOS-level access and control of up to 32 servers. . In addition, it's the industry's only dual-power KVM-over-IP switch. DKX2-232 works standalone or with our CommandCenter Secure Gateway centralized management appliance.

    The DKX2-232 offers the industry's highest video resolution 1600 x 1200. Allows remote installation of software, file transferring and data back up with Universal Virtual Media. And 128-bit SSL AES or RC4 encryption. Offers the tightest mouse in the industry, reducing installation time with Absolute Mouse Synchronization. Controls power to servers with optional remote power unit. Comes standard with dual power and dual gigabit Ethernet with automatic failover. The Dominion KX II provides dual stack IP networking with simultaneous support of IPv4 and IPv6. Features Virtual KVM Desktop™, a common browser-based user interface that supports the industry's widest range of operating systems and browsers. Plus, it includes the industry's first and only browser-based local access.

The Dominion KX II solution consists of the KVM-over-IP switch and Computer Interface Modules (CIMs).
  • CIMs connect to the server's KVM ports and can be located up to 150 feet away from the switch using UTP (Cat5/5e/6) cabling. CIMs also provide keep-alive keyboard/mouse emulation
  • Access from Windows®, Linux®, Sun® or Mac desktops via a wide range of Web-browsers or standalone client
  • Raritan's remote client software is automatically downloaded via Web browser; standalone multi-platform client available for emergency modem access
  • Provides its entire feature set out of the box: Virtual Media, 128- or 256-bit AES or RC4 encryption, dual power supplies and dual gigabit Ethernet ports with failover, SNMP, Syslog, as well as integration with LDAP, Radius and Active Directory® authentication. Support of IBM, HP, & Dell blade servers
